Sharing Caddy Across Multiple Elixir/Phoenix Services on a Single VPS

How we migrated from a bundled Caddy reverse proxy to caddy-docker-proxy for label-based, zero-config routing across multiple Docker Compose stacks.

iMORPHr · · 14 min read
Sharing Caddy Across Multiple Elixir/Phoenix Services on a Single VPS

The Starting Point

We run iMORPHr — an Elixir/Phoenix LiveView application — on a Hetzner VPS. The setup is straightforward: a single docker-compose.yml bundles the Phoenix app with a Caddy reverse proxy. Caddy handles TLS termination via Let’s Encrypt and proxies traffic to the app on port 4000.

The VPS directory structure looks like this:

/root/imorphr/
├── docker-compose.yml    # app + caddy
├── Caddyfile             # routing rules
└── .env                  # secrets

The docker-compose.yml:

services:
  app:
    image: ghcr.io/imorphr/imorphr-site:latest
    restart: always
    env_file: .env
    expose:
      - "4000"

  caddy:
    image: caddy:2-alpine
    restart: always
    ports:
      - "80:80"
      - "443:443"
    volumes:
      - ./Caddyfile:/etc/caddy/Caddyfile
      - caddy_data:/data
      - caddy_config:/config
    depends_on:
      - app

volumes:
  caddy_data:
  caddy_config:

And the Caddyfile:

www.imorphr.com {
    redir https://imorphr.com{uri}
}

imorphr.com {
    reverse_proxy app:4000
}

Simple. Caddy and the app live in the same Compose stack, share the default Docker network, and Caddy reaches the app by its service name app. GitHub Actions builds the Docker image, pushes to GHCR, SCPs the compose file and Caddyfile to the VPS, and runs docker compose up -d.

This worked perfectly — until we needed to deploy a second service.

The Problem: A Second Service Needs the Same Reverse Proxy

We’re building ShoppeX — an API backend (also Elixir/Phoenix) that helps independent UK shopkeepers compare wholesale prices. It needs to be deployed to the same VPS as api.imorphr.com.

ShoppeX’s docker-compose.prod.yml was already written with this in mind:

services:
  shoppex:
    image: ghcr.io/imorphr/shoppex:latest
    restart: unless-stopped
    ports:
      - "127.0.0.1:4000:4000"
    environment:
      DATABASE_URL: "${DATABASE_URL}"
      SECRET_KEY_BASE: "${SECRET_KEY_BASE}"
      PHX_HOST: "api.imorphr.com"
      # ... more env vars
    extra_hosts:
      - "host.docker.internal:host-gateway"
    networks:
      - caddy

networks:
  caddy:
    external: true

It referenced an external caddy network and included a comment saying “add this snippet to your shared Caddyfile”:

api.imorphr.com {
    reverse_proxy shoppex:4000
}

But here’s the rub: the Caddyfile is owned by the iMORPHr website repo. Every time iMORPHr deploys, it SCPs its own Caddyfile to the VPS. To add ShoppeX’s route, we’d have to modify the iMORPHr repo — creating a cross-repo dependency. The website would need to know about every other service on the VPS. That doesn’t scale, and it couples things that shouldn’t be coupled.

We also had a networking problem. The iMORPHr Compose stack uses Docker’s default network — app and caddy can see each other because they’re in the same stack. But ShoppeX is in a separate Compose stack. For Caddy to route to ShoppeX, both containers need to be on the same Docker network.

Approaches We Considered

Approach 1: Just Edit the iMORPHr Caddyfile

The simplest approach: add api.imorphr.com { reverse_proxy shoppex:4000 } to the iMORPHr repo’s Caddyfile. Create a shared external Docker network. Connect Caddy to both the default network (for the iMORPHr app) and the external network (for ShoppeX).

The iMORPHr compose would look like:

services:
  app:
    # ... unchanged
  caddy:
    # ... unchanged except:
    networks:
      - default
      - caddy

networks:
  caddy:
    external: true

Pros:

  • Minimal changes
  • Keeps the existing architecture

Cons:

  • The iMORPHr repo must know about every service on the VPS
  • Adding a third service means another PR to the iMORPHr repo
  • Cross-repo coupling — the website’s Caddyfile becomes shared infrastructure disguised as an app config file

We rejected this one quickly. It works today but creates a maintenance headache.

Approach 2: Extract Caddy Into Its Own Standalone Stack

Pull Caddy out of the iMORPHr repo entirely. Give it its own directory on the VPS and its own Compose file. The Caddyfile lives on the VPS, managed independently of any app.

/root/imorphr/
├── caddy/
│   ├── docker-compose.yml   # Just Caddy
│   └── Caddyfile            # All routes, managed on VPS
├── imorphr/
│   ├── docker-compose.yml   # Just the app
│   └── .env
└── shoppex/
    ├── docker-compose.prod.yml
    └── .env

Pros:

  • Clean separation — Caddy is infrastructure, not part of any app
  • Each app’s compose only needs to join the shared caddy network

Cons:

  • The Caddyfile is still a single file that needs to know about all services
  • Adding a new service still means SSH’ing into the VPS and editing the Caddyfile (or building automation for it)
  • The Caddyfile isn’t version-controlled by the services that depend on it

This was better, but still required centralized knowledge of all routes.

Approach 3: caddy-docker-proxy With Label-Based Auto-Discovery

Replace standard Caddy with caddy-docker-proxy. This is a Caddy build that watches the Docker socket and auto-generates routing configuration from container labels. There is no Caddyfile at all.

Each service declares its own routing:

# iMORPHr website
labels:
  caddy_0: imorphr.com
  caddy_0.reverse_proxy: "{{upstreams 4000}}"
  caddy_1: www.imorphr.com
  caddy_1.redir: "https://imorphr.com{uri} permanent"
# ShoppeX API
labels:
  caddy: api.imorphr.com
  caddy.reverse_proxy: "{{upstreams 4000}}"

Pros:

  • Each service owns its own routing — fully self-contained
  • Adding a new service = add labels to its compose file. No other repo touched.
  • No Caddyfile to manage anywhere
  • TLS still automatic via Let’s Encrypt
  • Caddy reloads with zero downtime when containers start/stop

Cons:

  • Introduces a dependency on a third-party Caddy plugin
  • One-time migration effort
  • Slightly less familiar than a plain Caddyfile

We chose this approach. The self-service nature of label-based routing is exactly what a multi-service VPS needs. Each team (or repo) is autonomous.

Deep Dive: How caddy-docker-proxy Works

caddy-docker-proxy is a custom Caddy build that includes a module for watching Docker. Here’s what happens:

  1. Caddy starts and connects to the Docker socket (/var/run/docker.sock)
  2. It scans all running containers on a specified network for labels prefixed with caddy
  3. Labels are translated into a Caddyfile in memory:
caddy: example.com                    →  example.com {
caddy.reverse_proxy: "{{upstreams}}"  →      reverse_proxy <container-ip>:80
                                      →  }
  1. Caddy applies the generated config — TLS certificates are provisioned automatically
  2. When containers start or stop, caddy-docker-proxy detects the event and triggers a graceful reload (no downtime)

Key Label Patterns

Basic reverse proxy:

labels:
  caddy: example.com
  caddy.reverse_proxy: "{{upstreams 4000}}"

Multiple site blocks from one container (using _0, _1 suffixes):

labels:
  caddy_0: example.com
  caddy_0.reverse_proxy: "{{upstreams 4000}}"
  caddy_1: www.example.com
  caddy_1.redir: "https://example.com{uri} permanent"

This is needed because YAML doesn’t allow duplicate keys. The _0 and _1 suffixes create separate, isolated Caddy site blocks.

The {{upstreams}} template resolves to the container’s IP address on the shared network. You can specify a port: {{upstreams 4000}}. caddy-docker-proxy handles the DNS resolution — you never hardcode IPs.

Important Configuration

The CADDY_INGRESS_NETWORKS environment variable is critical. It tells caddy-docker-proxy which Docker network to watch. Without it, auto-detection can be unreliable:

environment:
  - CADDY_INGRESS_NETWORKS=caddy

Debugging

The generated Caddyfile is saved inside the container. To inspect what caddy-docker-proxy built:

docker exec caddy cat /config/caddy/Caddyfile.autosave

This is invaluable for debugging routing issues.

The Final Architecture

Here’s what we ended up with — three independent Compose stacks sharing a single external Docker network:

                    ┌──────────────────────────────────────────────────┐
                    │  Hetzner VPS (Ubuntu 24.04)                      │
                    │                                                  │
  Internet          │  ┌────────────────────────────────────────────┐  │
  ──────▶ :443 ────▶│  │  caddy-docker-proxy                       │  │
                    │  │  (watches Docker labels, auto-configures)  │  │
                    │  │  Ports: 80, 443                            │  │
                    │  └─────────┬──────────────────┬───────────────┘  │
                    │            │                  │                   │
                    │  ┌─────────▼──────────┐  ┌───▼────────────────┐  │
                    │  │  iMORPHr site      │  │  ShoppeX API       │  │
                    │  │  imorphr.com       │  │  api.imorphr.com   │  │
                    │  │  Port 4000         │  │  Port 4000         │  │
                    │  └────────────────────┘  └────────┬───────────┘  │
                    │                                   │              │
                    │                          ┌────────▼───────────┐  │
                    │                          │  PostgreSQL 16     │  │
                    │                          │  (native, :5432)   │  │
                    │                          └────────────────────┘  │
                    │                                                  │
                    │  All app containers on shared "caddy" network    │
                    └──────────────────────────────────────────────────┘

VPS Directory Layout

/root/imorphr/
├── caddy/
│   └── docker-compose.yml       # caddy-docker-proxy (shared infrastructure)
├── docker-compose.yml            # iMORPHr website (app only, with labels)
├── .env                          # iMORPHr secrets
└── shoppex/
    ├── docker-compose.prod.yml   # ShoppeX API (app only, with labels)
    └── .env                      # ShoppeX secrets

The Three Compose Files

1. Caddy Infrastructure (/root/imorphr/caddy/docker-compose.yml)

This is shared infrastructure — deployed once, used by all services:

services:
  caddy:
    image: lucaslorentz/caddy-docker-proxy:2.12-alpine
    container_name: caddy
    restart: unless-stopped
    ports:
      - "80:80"
      - "443:443/tcp"
      - "443:443/udp"       # HTTP/3 (QUIC) support
    environment:
      - CADDY_INGRESS_NETWORKS=caddy
    networks:
      - caddy
    volumes:
      - /var/run/docker.sock:/var/run/docker.sock
      - caddy_data:/data     # TLS certificates — must persist
      - caddy_config:/config # debug: docker exec caddy cat /config/caddy/Caddyfile.autosave

networks:
  caddy:
    external: true

volumes:
  caddy_data:
  caddy_config:

Key points:

  • lucaslorentz/caddy-docker-proxy:2.12-alpine — pinned to minor version for stability, Alpine for shell access during debugging
  • /var/run/docker.sock mounted read-only so caddy can watch container events
  • caddy_data volume persists TLS certificates across restarts (losing this means re-issuing certs and potentially hitting Let’s Encrypt rate limits)
  • CADDY_INGRESS_NETWORKS=caddy explicitly tells it which network to watch
  • UDP port 443 enables HTTP/3 (QUIC)

2. iMORPHr Website (updated docker-compose.yml)

Caddy is gone. The app declares its own routing:

services:
  app:
    image: ghcr.io/imorphr/imorphr-site:latest
    restart: always
    env_file: .env
    expose:
      - "4000"
    networks:
      - caddy
    labels:
      caddy_0: imorphr.com
      caddy_0.reverse_proxy: "{{upstreams 4000}}"
      caddy_1: www.imorphr.com
      caddy_1.redir: "https://imorphr.com{uri} permanent"

networks:
  caddy:
    external: true

The caddy_0 / caddy_1 pattern creates two separate Caddy site blocks: one for the main domain with a reverse proxy, and one for the www subdomain with a permanent redirect.

No ports: mapping to the host — Caddy reaches the app entirely through the Docker network. The app is not directly accessible from the internet.

3. ShoppeX API (docker-compose.prod.yml)

services:
  shoppex:
    image: ghcr.io/imorphr/shoppex:latest
    restart: unless-stopped
    expose:
      - "4000"
    ports:
      - "127.0.0.1:4001:4000"
    environment:
      DATABASE_URL: "${DATABASE_URL}"
      SECRET_KEY_BASE: "${SECRET_KEY_BASE}"
      PHX_HOST: "api.imorphr.com"
      PHX_SERVER: "true"
      PORT: "4000"
      ECTO_SSL: "false"
      CLOAK_KEY: "${CLOAK_KEY}"
      PARFETTS_JWT: "${PARFETTS_JWT}"
      PARFETTS_BRANCH_ID: "${PARFETTS_BRANCH_ID}"
      PARFETTS_CUSTOMER: "${PARFETTS_CUSTOMER}"
    extra_hosts:
      - "host.docker.internal:host-gateway"
    networks:
      - caddy
    labels:
      caddy: api.imorphr.com
      caddy.reverse_proxy: "{{upstreams 4000}}"

networks:
  caddy:
    external: true

Note the ports: "127.0.0.1:4001:4000" — this binds to localhost on port 4001 for health checks during deployment. It’s not accessible from the internet (loopback only). Caddy routes public traffic through the Docker network.

The extra_hosts entry maps host.docker.internal to the host machine’s IP, allowing the container to reach PostgreSQL which runs natively (not in Docker) on the VPS.

CI/CD: Each Repo Deploys Independently

Caddy Infrastructure

The caddy_infra repo has a simple deploy workflow — no image build, just SCP the compose file and restart:

name: Deploy Caddy
on:
  push:
    branches: [main]

jobs:
  deploy:
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v4

      - name: Setup Tailscale
        uses: tailscale/github-action@v2
        with:
          oauth-client-id: ${{ secrets.TS_OAUTH_CLIENT_ID }}
          oauth-secret: ${{ secrets.TS_OAUTH_SECRET }}
          tags: tag:ci

      - name: Deploy to VPS
        run: |
          ssh -o StrictHostKeyChecking=accept-new ${{ secrets.DEPLOY_USER }}@${{ secrets.DEPLOY_HOST }} \
            "mkdir -p /root/imorphr/caddy"
          scp docker-compose.yml \
            ${{ secrets.DEPLOY_USER }}@${{ secrets.DEPLOY_HOST }}:/root/imorphr/caddy/docker-compose.yml
          ssh ${{ secrets.DEPLOY_USER }}@${{ secrets.DEPLOY_HOST }} << 'EOF'
          docker network create caddy 2>/dev/null || true
          cd /root/imorphr/caddy
          docker compose pull
          docker compose up -d
          EOF

The docker network create caddy 2>/dev/null || true is idempotent — it creates the network if it doesn’t exist, silently succeeds if it does.

ShoppeX

ShoppeX’s deploy workflow builds the Docker image, pushes to GHCR, and deploys. The only change from the original is the health check port:

# Before
if curl -sf http://localhost:4000/api/v1/health > /dev/null 2>&1; then

# After
if curl -sf http://localhost:4001/api/v1/health > /dev/null 2>&1; then

iMORPHr Website

The deploy workflow removes the Caddyfile SCP and the caddy-related concerns. It just deploys the app container.

The Migration Plan

This is a one-time procedure with ~30 seconds of downtime.

Prerequisites

  • DNS A record for api.imorphr.com pointing to the VPS IP (needed for Let’s Encrypt domain validation)
  • The caddy_infra repo created and pushed to GitHub with secrets configured

Steps

# 1. Deploy caddy_infra (creates the network and starts caddy-docker-proxy)
#    Trigger via GitHub Actions push to main, or manually:
ssh vps "docker network create caddy"
scp caddy_infra/docker-compose.yml vps:/root/imorphr/caddy/docker-compose.yml
ssh vps "cd /root/imorphr/caddy && docker compose up -d"

# 2. Stop the old iMORPHr stack (brief downtime starts)
ssh vps "cd /root/imorphr && docker compose down"

# 3. Deploy updated iMORPHr compose (with labels, no caddy service)
scp deploy/docker-compose.yml vps:/root/imorphr/docker-compose.yml
ssh vps "cd /root/imorphr && docker compose up -d"
# caddy-docker-proxy detects the new container and configures routing
# Let's Encrypt issues certs for imorphr.com — downtime ends

# 4. Verify iMORPHr is working
curl -I https://imorphr.com
curl -I https://www.imorphr.com   # should 301 redirect

# 5. Deploy ShoppeX (whenever ready)
# Standard deploy via GitHub Actions — caddy-docker-proxy auto-discovers it

# 6. Verify ShoppeX
curl -I https://api.imorphr.com/api/v1/health

# 7. Clean up old volumes
ssh vps "docker volume rm imorphr_caddy_data imorphr_caddy_config"

Rollback

If anything goes wrong, the old setup can be restored:

# Stop caddy-docker-proxy
ssh vps "cd /root/imorphr/caddy && docker compose down"

# Restore original compose + Caddyfile
scp original/docker-compose.yml vps:/root/imorphr/docker-compose.yml
scp original/Caddyfile vps:/root/imorphr/Caddyfile
ssh vps "cd /root/imorphr && docker compose up -d"

Gotchas and Lessons Learned

1. The caddy_data Volume Is Sacred

This volume stores TLS certificates. If you lose it, Caddy re-issues certificates on restart. Let’s Encrypt has rate limits: 5 duplicate certificates per domain per week. During testing, use the Let’s Encrypt staging environment:

labels:
  caddy.tls.ca: https://acme-staging-v02.api.letsencrypt.org/directory

Remove this label once everything works to get real production certificates.

2. Don’t Put Databases on the Caddy Network

Only web-facing containers need to join the caddy network. Database containers, Redis, internal workers — these should stay on their own isolated network. It’s both a security concern (unnecessary exposure) and can cause routing confusion.

3. YAML Doesn’t Allow Duplicate Keys

This won’t work:

labels:
  caddy: imorphr.com
  caddy: www.imorphr.com    # silently overwrites the first one!

Use caddy_0, caddy_1 suffixes for multiple site blocks from a single container.

4. Both Services Use Port 4000 — And That’s Fine

Both the iMORPHr app and ShoppeX listen on port 4000 inside their containers. This isn’t a conflict because Docker containers have isolated network namespaces. Caddy reaches each container by its IP on the shared Docker network, not by a host port. The host port binding (127.0.0.1:4001:4000 for ShoppeX) is only for health checks.

5. CADDY_INGRESS_NETWORKS Must Be Set Explicitly

Auto-detection of the ingress network is documented as unreliable. Always set it:

environment:
  - CADDY_INGRESS_NETWORKS=caddy

6. Debug the Generated Config

When things aren’t routing correctly, inspect what caddy-docker-proxy actually generated:

docker exec caddy cat /config/caddy/Caddyfile.autosave

This shows the exact Caddyfile that Caddy is running — including resolved IP addresses.

Adding a Third Service in the Future

This is where the approach pays off. Say we want to deploy a new service at dashboard.imorphr.com. All we need is:

services:
  dashboard:
    image: ghcr.io/imorphr/dashboard:latest
    networks:
      - caddy
    labels:
      caddy: dashboard.imorphr.com
      caddy.reverse_proxy: "{{upstreams 3000}}"

networks:
  caddy:
    external: true

No changes to Caddy. No changes to any other service. Deploy, and caddy-docker-proxy picks it up automatically. TLS certificates are provisioned within seconds.

Summary

Before After
Caddy Bundled in iMORPHr’s compose Standalone caddy-docker-proxy
Routing config Caddyfile in one repo Docker labels on each container
Adding a service Edit another repo’s Caddyfile Add labels to your own compose
TLS Automatic (Caddy) Automatic (still Caddy)
Cross-repo coupling Yes — website knows about all services None — each service is self-contained
Network Default compose network Shared external caddy network

The one-time migration cost is modest (creating a new repo, updating two compose files, ~30 seconds of downtime). The ongoing benefit is that every future service deployment is fully autonomous — no coordination, no shared config files, no cross-repo PRs.

For a small team running multiple services on a single VPS, this is the right level of infrastructure. It’s simpler than Kubernetes, more capable than a single Caddyfile, and stays out of the way.

← Back to Blog Work with iMORPHr →
